What is gallium nitride, and why is it called a "third-generation" semiconductor?
Gallium nitride is a wide-bandgap compound semiconductor that handles higher power, higher frequencies, and higher temperatures than silicon while staying smaller and more efficient. It belongs to the family engineers call "third-generation" semiconductors — silicon being first-generation, and materials like gallium arsenide second-generation — because the manufacturing physics, not just the chip design, had to be re-learned from scratch (India Today, 2026).
The property that matters is the bandgap: GaN's is about 3.4 eV versus silicon's 1.1 eV. A wider bandgap means the material can hold off much higher voltage before it breaks down, switch on and off far faster, and shed heat more efficiently. Practically, that translates into power converters roughly 40% denser and meaningfully more efficient than silicon equivalents in the same physical form factor — which is exactly why a 54 V data center PSU reference design from Navitas used GaN to push 4.5 kW out of a form factor that previously delivered 3.2 kW with silicon (EEPower / Navitas, 2024).
In short: silicon is the workhorse for logic and memory. GaN is the specialist for high-power, high-frequency switching — the places silicon physically maxes out.
Where is gallium nitride actually used today?
GaN parts are load-bearing in five categories, and the list explains why a country would want domestic control of the supply:
- Defense RF and radar — GaN power amplifiers drive active electronically scanned array (AESA) radars, electronic warfare transmitters, and missile seekers. India's Ministry of Defence signed Agnit to design GaN semiconductors for next-generation wireless transmitters in radars and electronic warfare systems in December 2023 (India Today, 2026).
- 5G and 6G radio units — GaN-on-SiC power amplifiers sit in the macro-cell base stations carrying the network. Industry analysis flags 5G massive-MIMO rollouts across Asia and India as a +4.1% accelerant on GaN market CAGR (Mordor Intelligence, 2026).
- EV fast chargers and on-board chargers — the 65–240 W USB-C PD GaN charger market, led by Chinese OEMs, is a short-term driver; the shift to 800 V EV platforms driving bidirectional GaN on-board chargers and DC-DC conversion is a medium-term one (Mordor Intelligence, 2026).
- AI data center power supplies — as rack power densities push past 100 kW on architectures like NVIDIA Blackwell NVL72, the industry is moving from 12 V to 48 V rails and from silicon to a hybrid GaN + SiC power chain: SiC for the high-voltage AC-DC shelf, GaN for the 48 V DC-DC motherboard stage (WhyChips, 2025; Infineon whitepaper, 2024).
- Satellite communications — GaN RF power is increasingly used in satcom terminals and ground stations as the NewSpace buildout scales.
The unifying thread: every one of these is a market where power density, thermal headroom, and switching speed matter more than raw transistor count — which is precisely where silicon runs out of room and GaN is the only practical alternative.
Who is Agnit Semiconductors, and what did IISc actually build?
Agnit Semiconductors Private Limited is a Bengaluru-based, vertically integrated gallium nitride startup spun out of 15 years of compound-semiconductor research at the Indian Institute of Science. It was founded in 2019 and became a functioning enterprise in 2021 (India Today, 2026; Evertiq, 2024).
The founding team is genuinely a research-to-enterprise bridge — it includes Hareesh Chandrasekar (CEO and co-founder), Digbijoy Nath (CTO and co-founder, also an IISc associate professor who describes GaN's value as "a wide bandgap semiconductor material that has the capacity to handle high power applications and operates at higher frequencies and perform more efficiently than traditional silicon"), Srinivasan Raghavan (IISc professor and co-founder), and others, with the founding team collectively carrying over a century of aggregate experience across the full semiconductor value chain (India Today, 2026; Agnit via Fundz, 2026).
What sets Agnit apart — and why multiple independent industry sources confirm it as India's first and only startup able to take GaN from raw wafer growth to finished RF modules entirely in-house — is that vertical integration. Most GaN players globally specialize in one stage: wafer growth, or device fabrication, or module packaging. Agnit's 15 years of IISc research gave it differentiated IP across materials, processes, and devices, which is the rarest combination in a capital-light startup because it normally takes a full fab to develop.
Agnit is also one of the first companies incubated at the Gallium Nitride Ecosystem Enabling Centre and Incubator, managed by the Foundation for Science Innovation and Development (FSID) at IISc and funded by the Ministry of Electronics and Information Technology (MeitY) — the institutional scaffolding that turned an academic research line into a company (Evertiq, 2024).
How much has Agnit raised, and how does it compare to India's silicon ambitions?
| Metric | Agnit Semiconductors (GaN) | Tata Electronics, Dholera (silicon) |
|---|---|---|
| Total investment | $7.47 million (3 seed rounds, 2024–2026) | > ₹91,000 crore (~$11 billion) |
| Capacity | Slewing toward ~100,000 GaN components over two years | 50,000 wafers starts per month (WSPM) |
| Material | Gallium nitride (compound semiconductor) | Silicon |
| Funding sources | 3one4 Capital, Zephyr Peacock, Shastra VC, Lakshmi Narayanan; MeitY/FSID incubation | 50% fiscal support from India Semiconductor Mission, pari-passu |
| First commercial output | GaN RF/wafer prototypes via MoD iDEX (2023) | Commercial fab, partnership with PSMC (Taiwan) |
Sources: Tracxn / Fundz, 2026; siliconindia, 2024; PIB, 2025; DD News, 2025.
The two are not building the same thing, and the comparison can mislead if read carelessly. The Dholera fab is silicon at industrial scale for automotive, computing, communications, and AI-adjacent chips with a technology-transfer partner (Taiwan's PSMC). Agnit is compound semiconductors at startup scale, with no foreign tech partner because there was no partner to buy it from — the IP was generated domestically. But the ratio is the honest part: Tata's single project is more than 1,400× the entire capital Agnit has ever raised, against a domestic GaN devices market that Grand View Research sized at $174.6 million in 2025 and projects at $1,879.8 million by 2033 (35.5% CAGR, 2026–2033) (Grand View Research, 2026).
The takeaway is not "Agnit is underfunded." It is that India's entire compound-semiconductor strategy currently rides on one seven-person startup and one government-funded small-volume foundry at IISc. Whether that becomes a cluster or stays a proof-of-concept depends almost entirely on what gets raised next.
Why does gallium nitride matter for AI infrastructure, specifically?
This is the angle most coverage of Agnit misses. The GPU shortage gets the headlines, but the binding constraint on the next wave of AI compute is power delivery, not silicon logic. As rack power densities push past 100 kW on architectures like NVIDIA's Blackwell NVL72, the industry is moving from 12 V to 48 V rails to cut resistive I²R losses by roughly 16× — and on the motherboard stage, that 48 V DC-DC conversion is being won by GaN, with SiC handling the higher-voltage AC-DC shelf stage (WhyChips, 2025; Infineon whitepaper, 2024).
An arXiv survey of GaN power devices in AI data centers frames it bluntly: GaN's high electron mobility and fast switching let power supplies run at higher frequency with lower conduction losses, which is the only way to hit the efficiency and density targets AI racks now demand (arXiv 2606.25281, 2026). Navitas Semiconductor's 4.5 kW reference design — a 40% power uplift from the silicon-baseline 3.2 kW in the same CRPS185 form factor — is a concrete, citable proof point (EEPower / Navitas, 2024).
So for anyone building or buying AI infrastructure in 2026, gallium nitride is not an exotic lab curiosity. It is the material whose availability and cost will quietly decide how dense and how efficient your next AI rack can be. A domestic GaN supply chain, even a small one, is a strategic hedge on the most under-discussed bottleneck in AI compute — which is why NVIDIA's own $500B SK Group infrastructure deal, covered in our analysis of the NVIDIA–SK Group agreement, explicitly locks in HBM4 memory and AI factory builds rather than just GPUs.
How does gallium nitride actually beat silicon, quantitatively?
| Property | Silicon (Si) | Gallium nitride (GaN) | Why it matters |
|---|---|---|---|
| Bandgap | ~1.1 eV | ~3.4 eV | Higher breakdown voltage; tolerates higher operating temperatures |
| Electron mobility | ~1,400 cm²/V·s | ~2,000 cm²/V·s (2DEG much higher) | Faster switching; smaller passives; less heat lost to resistance |
| Critical electric field | ~0.3 MV/cm | ~3.3 MV/cm | Device can hold off ~10× the voltage for the same thickness |
| Thermal conductivity | 1.5 W/cm·K | 1.3 W/cm·K (bulk); better in GaN-on-SiC | Heat is real but manageable with the right substrate |
| Practical outcome | ~3.2 kW PSU in CRPS185 form factor | ~4.5 kW PSU in same form factor (+40%) | Density and efficiency in AI racks, EV chargers, RF PA |
Sources: EEPower / Navitas reference design, 2024; WhyChips, 2025.
The numbers explain both the excitement and the cost: GaN delivers a step change in power density at exactly the voltage nodes the AI, EV, and 5G build-outs live at. But each wafer costs meaningfully more than silicon, the supply base is far smaller, and there is no commodity recycling pathway yet — the real tradeoff is higher upfront device cost in exchange for lower system-level energy and cooling spend over the product life.
What this means for you
- If you build or spec AI infrastructure: gallium nitride is no longer an optional efficiency lever — it is becoming the default on the 48 V DC-DC stage of every new AI rack. Plan PSU and power-shelf roadmaps around GaN + SiC hybrid architectures, not silicon-only, and price in the supply base concentration risk.
- If you invest in Indian deep-tech: Agnit is a category-of-one right now — India's only vertically integrated GaN IDM — which is both the opportunity (monopoly capability, defense contract, IESA Semiconductor Startup Award 2025, NASSCOM DeepTech Emerge 50) and the concentration risk. The next funding round, not the current $7.47M, is the one that decides whether a domestic GaN cluster forms around it.
- If you work in defense procurement or telecom: domestic GaN capability is the difference between buying components someone else built for someone else's roadmap and specifying India-built parts on India's own 10-year roadmap — which is exactly the framing Agnit's CEO uses, and it is the part of the story that travels least into the consumer press.
- If you are a small business or builder watching the chip headlines: understand that the "India semiconductor" story you read about (Tata, CG Power, the giant fabs) is silicon. The strategically more interesting and far less crowded lane is compound semiconductors — Agnit's lane. Our piece on why most enterprise AI projects never scale makes the analog point about AI: the bottleneck is rarely the headline technology, and almost always the under-invested layer underneath it. For GaN, the under-invested layer is domestic wafer and device capacity.
FAQ
Q: What is gallium nitride used for? A: Gallium nitride (GaN) is a wide-bandgap semiconductor used wherever silicon reaches its power, frequency, or thermal limits — AESA radars and electronic warfare, 5G/6G radio units, EV fast chargers and on-board chargers, satellite communications, and the 48 V power supplies feeding AI data center racks.
Q: Is Agnit Semiconductors really India's only gallium nitride startup? A: Agnit is consistently described by independent industry sources and its investors as India's first and only vertically integrated GaN startup — meaning it can take GaN from raw wafer growth to finished RF modules in-house, built on 15 years of IISc research (India Today, 2026; Evertiq, 2024).
Q: How big is the gallium nitride market in India? A: Grand View Research estimates India's GaN semiconductor devices market at $174.6 million in 2025, projected to reach $1,879.8 million by 2033 at a 35.5% CAGR (2026–2033), with power semiconductors as the largest 2025 segment and GaN radio-frequency devices the fastest-growing (Grand View Research, 2026).
Q: How much has Agnit Semiconductors raised? A: Agnit has raised a total of $7.47 million across three seed rounds as of 2026, including a $3.5 million seed in October 2024 led by 3one4 Capital and Zephyr Peacock, and a $2.6 million seed extension led by Shastra VC with 3one4 Capital and Zephyr Peacock participating (siliconindia, 2024; Fundz, 2026).
Q: Is gallium nitride better than silicon? A: GaN is not a drop-in replacement for silicon — it is a specialist for high-power, high-frequency switching. Its ~3.4 eV bandgap, higher critical electric field, and faster electron mobility let it deliver roughly 40% more power density than silicon in the same form factor at the 48 V / RF voltage nodes, which is why it wins in AI rack power supplies, EV chargers, and 5G base stations while silicon remains the logic and memory workhorse (EEPower, 2024; WhyChips, 2025).
Q: Where is the Tata semiconductor fab, and is it the same as Agnit? A: No. Tata Electronics' commercial silicon fab is in Dholera Special Investment Region, Gujarat (not Dehradun — a common mis-citation), at over ₹91,000 crore (~$11 billion) investment and 50,000 wafers starts per month, in partnership with Taiwan's PSMC (PIB, 2025). Agnit is a separate compound-semiconductor (GaN) startup in Bengaluru at startup scale — the two are building different materials for different markets.
Q: Why does gallium nitride matter for AI data centers? A: As AI racks push past 100 kW on designs like NVIDIA Blackwell NVL72, the industry is shifting from 12 V to 48 V rails and from silicon-only to a hybrid GaN + SiC power chain. GaN's fast, efficient switching at the 48 V DC-DC motherboard stage is the main lever hitting the efficiency and density targets AI racks now require (Infineon whitepaper, 2024; arXiv 2606.25281, 2026).
