Verdict: India has officially transitioned from a chip design powerhouse to a commercial semiconductor manufacturing player. On June 19, 2026, CG Semi dispatched its first commercial shipment of assembled chips from Sanand, Gujarat, to Kuala Lumpur, marking the successful operationalization of the India Semiconductor Mission (ISM).
Last verified: 2026-07-02 · Hub: Sanand, Gujarat · Key Players: CG Semi, Micron, Kaynes Semicon · Incentive: ₹76,000 Crore ISM Fund.
For decades, India was known as the world’s "back office" for chip design, with nearly 20% of the world’s VLSI engineers working out of cities like Bengaluru and Hyderabad. However, the physical chips were always built elsewhere. That era ended in the first half of 2026 as three major facilities in Gujarat's Sanand district moved from foundation stones to commercial exports.
The Sanand Breakthrough: CG Semi’s First Shipment
On June 19, 2026, CG Semi—a joint venture between the Murugappa Group’s CG Power, Japan’s Renesas Electronics, and Thailand’s Stars Microelectronics—dispatched its first commercial consignment to Kuala Lumpur International Airport.
The shipment consists of assembled semiconductor chips destined for customers of Renesas Electronics, the JV’s anchor customer and technology partner. This milestone comes just 10 months after the pilot "G1" facility was inaugurated in August 2025.
Key stats for the CG Semi Sanand Facility: | Feature | Detail | |---------|--------| | Investment | ₹7,600 Crore ($910M approx.) over 5 years | | Ownership | CG Power (92.3%), Renesas (6.8%), Stars Microelectronics (0.9%) | | Capacity | G1 Pilot: 0.5 Million units/day; G2 (End 2026): 15 Million units/day | | Focus | OSAT (Assembly, Packaging, and Testing) | | Applications | Automotive, 5G, Consumer Electronics, Industrial |
The "Sanand Cluster": Three Plants in Four Months
CG Semi is not an isolated success. It is part of a rapidly maturing cluster in Sanand, often referred to as India’s "Silicon Valley for Assembly."
- Micron Technology (Feb 28, 2026): The first to inaugurate its $2.75 billion facility. It has already begun shipping "Made in India" memory modules (DRAM and NAND) to global partners, including Dell Technologies.
- Kaynes Semicon (March 31, 2026): Commenced commercial operations just a month later, focusing on advanced packaging for industrial and automotive sectors.
- CG Semi (June 19, 2026): Marked the third major operational milestone, specifically strengthening the India-Japan-Thailand supply chain corridor.
Why OSAT is the Right First Step
While global headlines often focus on massive "Fabs" (wafer fabrication plants like the one Tata Electronics is building in Dholera), the OSAT (Outsourced Semiconductor Assembly and Test) model is India's strategic entry point.
Fabs are hyper-capital-intensive, often requiring $10B+ and 3-5 years to build. OSAT facilities can be operational in 12-18 months. By mastering the "backend" first—assembly, testing, and packaging—India is building the necessary logistics, cleanroom expertise, and vendor ecosystems required to support the larger fabrication units coming in 2027 and 2028.
What This Means for Global Supply Chains
The entry of India into the OSAT market provides a critical "China+1" alternative for global tech giants. As the world shifts toward AI-first hardware, the demand for specialized packaging (like HBM for AI accelerators) is skyrocketing. India’s proximity to major shipping routes and its massive domestic electronics market makes it a logical hub for global players like Renesas and Micron.
What This Means for You
For business leaders and tech builders, the local availability of "Made in India" components means:
- Reduced Lead Times: Faster turnaround for locally manufactured hardware (laptops, EVs, industrial sensors).
- Supply Chain Resilience: Reduced reliance on single-region dependencies for critical components.
- Cost Efficiency: Potential long-term cost benefits as the domestic ecosystem matures and logistics costs drop.
Q: Is India making the actual silicon wafers yet? A: Not yet. Current shipments are from OSAT facilities that assemble and test wafers imported from global networks. India’s first commercial wafer Fab (Tata-PSMC in Dholera) is expected to be operational by late 2027.
Q: Which industries use chips from the Sanand facility? A: The chips are primarily used in automotive electronics (EVs), 5G telecommunications gear, consumer electronics (laptops/phones), and industrial power management systems.
Q: How much did the government subsidize these plants? A: Under the India Semiconductor Mission (ISM), the central government provides 50% fiscal support on a pari passu basis, with additional state-level incentives (e.g., Gujarat’s 20% support).
Q: Are these chips as good as those from Taiwan or Malaysia? A: Yes. These facilities use technology transferred from global leaders like Renesas (Japan) and Micron (USA), meeting identical global quality and reliability standards.
